| Model | View 31 TG ARGB |
|---|---|
| CASE TYPE | Mid Tower |
| Dimension (H x W x D) | 497 x 250 x 511 mm (19.5 x 9.8 x 20.1 inch) |
| PANEL | 4mm Tempered Glass x 2 (Left & Right) |
| Color | Exterior & Interior : Black |
| MATERIAL | SPCC |
| COOLING SYSTEM | Front (intake) : 140 x 140 x 25 mm ARGB fan (1000rpm, 22.8 dBA) x 2 Rear (exhaust) : 140 x 140 x 25 mm ARGB fan (1000rpm, 22.8 dBA) |
| Drive Bays -Accessible -Hidden |
- 3 x 3.5’’ or 2.5’’ (HDD Cage) |
| EXPANSION SLOTS | 8 + 2 |
| MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| I/O Port | USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, RGB Button x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: 3 x 120mm , 2 x 140mm , 1 x 200mm Top: 3 x 120mm , 3 x 140mm , 2 x 200mm Rear: 1 x 120mm , 1 x 140mm Bottom: 2 x 120mm , 2 x 140mm |
| RADIATOR SUPPORT | Front: 1 x 360mm , 1 x 280mm Top: 1 x 360mm , 1 x 280mm Rear: 1 x 120mm , 1 x 140mm Bottom: 1 x 120mm , 1 x 140mm |
| CLEARANCE | CPU cooler height limitation: 180mm VGA length limitation: 278mm(with HDD rack) 420mm(without HDD rack) PSU length limitation: 180mm (With One Bottom Fan) 220mm (Without Bottom Fan) |
